Spada Codatronza Monza - full details revealed!

Apr 01, 2011

as previously reported, the corvette-based codatronca monza by spadavetturesport will be introduced at the forthcoming top marques monaco supercar show.

just before the event the official information and first pictures of the new model are availabel below. enjoy!

press release:

spadaconcept extend its codatronca© scale, launched with the ts model, by a futuristic sport car  with  strong lines and shape; a car without compromise (you love it or you hate it! no space for “nice”) however it seems that this car has inspired lot of sports car of that segment as well as production supercars, above all in terms of front design and form language.

spadaconcept is a design studio-atelier founded by ercole spada (former designer zagato, bmw and idea institute), by paolo spada (ex designer smart and honda) and domiziano boschi (ex mc kinsey).

the studio combines an original formula of design all over the field  with a vision from the design to the economic feasibility. this mission has brought during these years to  different creations, like the stilo helmets for sebastién loeb , a eco-globe award for best design of an eclectic van, boats, motorsport sport accessories, watches. however the design studio has rooted  its chromosomes in the world of the sport cars: over the passion of the three founders for the authentic sport cars, the pencil of ercole spada and paolo spada include among their most important realisations one-off  and sport cars.

that is the reason why spadaconcept returns to present a powerful car with the racing instinct. born by the pencil of paolo and ercole spada the spada codatronca© monza, a extreme barchetta built by spadavetturesport s.r.l , originate from a request of a special client deciduous  of having a totally customized version of codatronca© around his own requirements.

from this one-off car, spadavetturesport is planning to let arise a small series, making another step forward to the research of aerodynamics, lightness, and pleasure of driving. codatronca© monza has the same guide lines that portrayed most of the project of ercole spada, like the mythical tz1 and tz2, were characterize by the back shape called “codatronca©”.

the codatronca© © monza has mechanic and electronic components developed by italtecnica, respecting the specification of the project needs, in this way we’ve obtained from the v8, in aluminium of more than 7lt with a dry pump, with a power of 700hp at 6200 rpm, with an incredible torque of 950nm at 4200 rpm. the power is transmitted to the ground by the rear wheels thanks to a 6 gear close ratio transmission with a specific range also at the 6th gear to the limit of 7000 rpm that push the codatronca© at 340 km/ h with an acceleration from 0 to 100km/ h of only 3,0 sec. the designers gave more importance to the pleasure of driving instead of speed record, in the perfect style of the gentleman driver. for support that performance, the codatronca© is fitted with a traction control on 3 level of action that progressively excludes only the traction control and after another push leaving the car to the bare control of its lucky owner. for a better check of the car’s data, codatronca© has an equipment that can record since 80 hours of telemetry on track, with 40 active channel (steering angle, g meter longitudinal and lateral, single speed for each tyre, lap timer and gps tracking system for track trajectories and lots more) the chassis is a light and stiff aluminium tubular with two roll bar combined for offer the maximum protection also when it’s driven on track. the bodywork is made of light and resistant fibre that cover the chassis and the mechanics parts.

the suspension are completely adjustable like the one of the racing cars. a big news is represented by the possibility of set up the anti-roll bar on the front and on the rear separately on 4 level of hardness: rain, soft, medium and hard with an on-board regulation. in that way the wheel can work at its best and the suspension in every condition, especially when the car is on track due to the selection of harden or soften the axles for a perfect grip. the wheels are the pirelli pzero corsa, with size 2285 / 35 / 19’’ for the front wheels and 345 / 35 / 19’’ for the back wheels. the rims are of 19’’ by oz, these were chosen to assure that the shoulder tyres transmit best the drive feelings of this fantastic tyres. the braking system is brembo with racing 8 pistons aluminium callipers on the front with discs of 380mm and with 4 pistons aluminium callipers with discs of 355mm on the rear; governed by an abs system of the latest generation.

the codatronca©® shape of the back gave the possibility to create a trunk, with a suitcase set purposely made by aznom srl.

the car is available at spadavetturesport in a limited number every year.

technical specifications

spada codatronca© monza

 vehicle type front-mid-engine, rwd 2-door roadster

structure : aluminum space frame combined with a magnesium engine cradle.

engine:

aluminum block v8 and cylinder head, eight-quart dry-sump lubrication system, titanium valves

type _______________7.0 v-8 with two italtecnica c38 rotrex centrifugal superchargers and two intercoolers.

displacement (cm3)_____________7011

compression ratio (:1)__________11.5

power (horsepower @ rpm)______700 @ 6200

torque (nm @ rpm)____________950 @ 4200

fuel feed____________________ sfi(sequential fuel injection)

valvetrain___________________ ohv, 2valves per cylinder

tranmission:

short – throw 6-speed manual

dimensions:

weight (kg) ____________________1180

wheelbase (mm)________________2686

track, front/rear (mm)____________1607/1580

length (mm)___________________4759

width (mm)_____________________1942

height (mm)____________________1130

suspension, streering, brakes:

front and rear suspension fully adjustable racing derived.

steering power-assisted, speed-sensitive, magnetic, variable-effort rack-and-pinion with fluid cooler.

brakes power-assisted disc with abs, 380mm front discs and 355mm rears,

8-piston front and 4-piston rear brembo calipers.

wheels:

front: 285/35-19”   rear: 345/35-19”

performance

top speed (km/h)________________335

acceleration 0-100 km/h (s)________3.0

source: www.spadaconcept.com, www.spadavetturesport.com, www.codatronca.com



2011-04 svs codatronca monza
